We’re proud to announce that we have teamed up with Creaform3d to offer its precise, supremely versatile 3D handheld scanners alongside our industry leading Opt2Sim Scan tube measurement system.
Since its launch, Opt2Sim Scan has been widely recognised as the premier measurement tool for the rapid scanning of tube geometry and easy extraction of tube data.
Our partnership with Creaform3d, however, is a real gamechanger – creating what is possibly the world’s most powerful, no-compromise portable 3D scanning metrology solution for tube and pipe measurement and reverse engineering. And all from a team with unrivalled tube bending and measurement expertise!
Simply use the Creaform3d portable handheld unit to scan the tube or component you wish to replicate or measure.
Extract its bending data in Opt2Sim Scan. Then easily compare measured tube dimensions to master file data and send corrections directly to the bending machine.
Offering considerable scan points without compromising speed, the constant reference geometry ensures supremely accurate results – without the need for a skilled operator to always place the part in the same position or enter some of the information pre-scan.
With Opt2Sim Scan sitting within our own suite of software, ‘compare to master’ and feedback to the bending machine is quick and seamless, without pausing the bending process. Plus, as the scanner is fully autonomous, it is easily combined with a cobot or robot to make it part of a manufacturing cell for 100% inspection.
Add our simulation package to replicate the entire bending process on a CAD-based model of your Unison Breeze or Unison Synergy machine and you’ve a precise, virtual insight into the tube bending process before a single physical part is bent.
To see just how affordable and easy to use Opt2Sim Scan with Creaform3d is, you need only talk to our experts at Southern Manufacturing & Electronics. Demonstrations will be taking place throughout the event at the Unison stand – D215, and at stand M165 where you’ll find Creaform3d’s UK agents, Measurement Solutions Ltd.
At a glance
To book your free Opt2Sim Scan with Creaform3d demonstration:
Email: sales@unisonltd.com
Call 01723 582868
